Jinko 625W Bifacial With Dual Glass Solar Panel
- Cell Type: N-Type Monocrystalline | 132 Cells (66×2) | Bifacial Dual-Glass Design
- Power Output (Pmax): 625W | Module Efficiency: 23.14% | Power Tolerance: 0~+3%
- Voltage (Vmp / Voc): 40.88V / 49.28V | Current (Imp / Isc): 15.29A / 16.14A
- Max System Voltage: 1500VDC (IEC) | Max Series Fuse: 35A | Bifacial Factor: 80±5%
- Build: 2.0mm Anti-Reflection Front Glass | 2.0mm Heat-Strengthened Back Glass | Anodized Aluminium Alloy Frame | IP68 Junction Box | Output Cable: 4.0mm²
- Load & Temperature: Operating Temp: -40°C~+85°C | Temp. Coefficient (Pmax): -0.29%/°C
- Dimensions & Weight: 2382 × 1134 × 30 mm | 32.4 kg
- 🛡️ Warranty: 12-Year Product Warranty | 30-Year Linear Power Output Warranty
- 🚚 Delivery:
- Inside Dhaka: Delivered within 1–2 business days.
- Outside Dhaka: Delivered within 2–3 business days.
Note: Delivery time may vary depending on courier service availability and delivery location.
Description
-
Mechanical Characteristics
Parameter Specification Cell Type N-type Mono-crystalline No. of Cells 132 (66×2) Dimensions 2382×1134×30 mm Weight 32.4 kg Front Glass 2.0 mm, Anti-reflection Coating Back Glass 2.0 mm, Heat Strengthened Glass Frame Anodized Aluminum Alloy Junction Box IP68 Rated Protection Class Class II IEC Fire Type Class C Output Cables 4.0 mm² (+): 400 mm, (-): 200 mm or Customized Length
Packaging Configuration
Item Details Pallet Dimensions 2396×1110×1251 mm Packing Detail 36 pcs/pallets, 72 pcs/stack, 720 pcs/40’HQ Container (Two Pallets One Stack)
Specifications (STC)
STC: Irradiance 1000W/m², Cell Temperature 25°C, AM = 1.5
Parameter 600 605 610 615 620 625 Maximum Power – Pmax (Wp) 600 605 610 615 620 625 Maximum Power Voltage – Vmp (V) 40.16 40.31 40.46 40.60 40.74 40.88 Maximum Power Current – Imp (A) 14.94 15.01 15.08 15.15 15.22 15.29 Open-circuit Voltage – Voc (V) 48.28 48.48 48.68 48.88 49.08 49.28 Short-circuit Current – Isc (A) 15.84 15.90 15.96 16.02 16.08 16.14 Module Efficiency STC (%) 22.21 22.40 22.58 22.77 22.95 23.14 Power Tolerance 0 ~ +3 % Temperature Coefficients of Pmax -0.29 %/°C Temperature Coefficients of Voc -0.25 %/°C Temperature Coefficients of Isc 0.045 %/°C
Specifications (NOCT)
NOCT: Irradiance 800W/m², Ambient Temperature 20°C, AM = 1.5, Wind Speed 1m/s
Parameter 600 605 610 615 620 625 Maximum Power – Pmax (Wp) 453 457 461 464 468 472 Maximum Power Voltage – Vmp (V) 37.60 37.67 37.92 38.10 38.25 38.44 Maximum Power Current – Imp (A) 12.05 12.10 12.15 12.19 12.24 12.28 Open-circuit Voltage – Voc (V) 45.86 46.05 46.24 46.43 46.62 46.81 Short-circuit Current – Isc (A) 12.79 12.83 12.88 12.93 12.98 13.03
Application Conditions
Parameter Specification Operating Temperature -40°C ~ +85°C Maximum System Voltage 1500 VDC (IEC) Maximum Series Fuse Rating 35 A Nominal Operating Cell Temperature – NOCT 45±2 °C Refer. Bifacial Factor 80±5 %
