DC Combiner Box | Solar PV String Combiner Box for Solar Power Systems
The DC Solar Combiner Box is designed to safely combine multiple photovoltaic (PV) string outputs into a single DC output for the inverter. Equipped with essential protection components such as DC fuses, surge protection devices (SPD), and DC isolator switches, it enhances the safety, reliability, and efficiency of solar power systems.
The DC Solar Combiner Box is a critical component in photovoltaic (PV) systems, engineered to collect and combine the output from multiple solar panel strings before transmitting power to the inverter. It simplifies system wiring, improves installation efficiency, and provides comprehensive protection for your solar power infrastructure.
Built with a weather-resistant enclosure and premium electrical components, the combiner box integrates DC fuses, surge protection devices (SPD), DC circuit breakers, and DC isolator switches to protect against overcurrent, lightning-induced surges, short circuits, and electrical faults. Its robust construction ensures reliable performance in harsh outdoor environments, including extreme temperatures, rain, dust, and UV exposure.
Designed for residential, commercial, and industrial solar installations, the DC Combiner Box supports easy maintenance, organized cable management, and enhanced system safety. Available in various input/output configurations, it is compatible with both on-grid and off-grid solar PV systems.
Whether you’re installing a rooftop solar system or a large-scale solar power plant, the DC Solar Combiner Box provides dependable protection, optimized power distribution, and long-lasting performance.
Key Features
- Combines Multiple PV Strings into One Output
- Integrated DC Fuse Protection
- Built-in DC Surge Protection Device (SPD)
- DC Isolator Switch for Safe Maintenance
- Weatherproof IP65 Enclosure
- UV & Corrosion Resistant Housing
- Easy DIN Rail Installation
- Safe & Organized Cable Management
- Reliable Outdoor Performance
- Suitable for Residential, Commercial & Industrial Applications
Applications
- Residential Solar Power Systems
- Commercial Rooftop Solar Projects
- Industrial Solar Installations
- Solar Farms
- Hybrid Solar Systems
- Off-Grid Solar Systems
- On-Grid Solar Systems
- Battery Energy Storage Systems (BESS)
Typical Specifications
| Feature | Details |
| Product Type | DC Solar Combiner Box |
| Input Strings | 2 / 4 / 6 / 8 / 12 / 16 (Model Dependent) |
| Output | 1 or Multiple Outputs |
| Rated Voltage | Up to 1000V DC / 1500V DC |
| Rated Current | 16A–32A per String (Model Dependent) |
| Protection | DC Fuse, DC MCB, DC SPD, DC Isolator |
| Enclosure Protection | IP65 |
| Mounting | Wall Mounted |
| Operating Temperature | -25°C to +60°C |
| Standards | IEC 61439, IEC 60947, IEC 61643 |
