Cable Tray Horizontal 90° Elbow | 90 Degree Cable Tray Bend for Cable Management
The Cable Tray Horizontal 90° Elbow is designed to change the direction of cable tray systems by 90 degrees on the horizontal plane. It ensures smooth cable routing, maintains proper cable bend radius, and provides a secure, reliable solution for commercial, industrial, and infrastructure cable management systems.
The Cable Tray Horizontal 90° Elbow is an essential cable management fitting engineered to create a 90-degree horizontal turn in cable tray systems while maintaining continuous cable support and protection. It allows cables to be routed safely around corners without excessive bending or mechanical stress, helping preserve cable performance and extend service life.
Manufactured from premium-quality pre-galvanized steel, hot-dip galvanized steel, stainless steel, or aluminum, the Horizontal 90° Elbow offers outstanding mechanical strength, corrosion resistance, and long-term durability. Its precision-engineered construction ensures perfect alignment with straight cable tray sections, allowing quick installation and secure connections.
Designed for use in commercial buildings, industrial plants, data centers, hospitals, airports, power plants, and infrastructure projects, this fitting provides efficient cable routing while supporting modern electrical and communication systems. It is compatible with perforated cable trays, ladder cable trays, and other cable support systems.
Key Features
- 90° Horizontal Cable Routing
- Smooth Cable Direction Change
- High Mechanical Strength
- Corrosion & Rust Resistant
- Heavy-Duty Construction
- Easy Installation
- Excellent Cable Protection
- Low Maintenance
- Long Service Life
- Compatible with Various Cable Tray Systems
Applications
- Commercial Buildings
- Industrial Facilities
- Data Centers
- Hospitals
- Airports
- Shopping Malls
- Manufacturing Plants
- Power Plants
- Telecommunication Networks
- Infrastructure Projects
Typical Specifications
| Feature | Details |
| Product Type | Cable Tray Horizontal 90° Elbow |
| Material | Pre-Galvanized Steel / Hot-Dip Galvanized Steel / Stainless Steel / Aluminum |
| Angle | 90° |
| Surface Finish | Pre-Galvanized / Hot-Dip Galvanized / Powder Coated |
| Width | 50mm–1000mm (Model Dependent) |
| Height | 25mm–150mm (Model Dependent) |
| Installation | Horizontal Direction Change |
| Compatibility | Ladder & Perforated Cable Tray Systems |
| Standards | IEC 61537 / NEMA VE 1 |
